More Pictures
CATEGORY
LANDING CRAFT TANKDimensions
45.00 x 9.00 x 02.70 Meters
Machinery
2 x 405 HP Yanmar
Build
New Build
Status
8 to 10 Months Lead Time
Description
Download Technical Drawing
Download Drawing 1
|
Code of Vessel |
: LCT 45 M |
|
Flag |
: Indonesia |
|
Type of Vessel |
: Steel Landing Craft Tank |
|
Classification |
: BKI |
|
Build Year |
: New Build |
|
Length Over All ( LOA ) |
: 45.00 meters |
|
Registered Breadth |
: 09.00 meters |
|
Registered Depth |
: 02.70 meters |
|
Loaded Draft |
: 02.60 meters |
|
Fresh Water Capacity |
: 25 tons |
|
Gross Tonnage |
: +/- 500 tons |
|
Cargo Tank Capacity |
: 500 tons |
|
Main Engine |
: 2 x 405 HP Yanmar |
|
Gear Box |
: 2 x Hangzhou D 300 A (New) ratio 1:4 |
|
Generator Set |
: 2 x YTG 40TL-M Genset Engine type Yanmar 4TNE 98-G1A, 33 KVA |
|
Speed |
: 8 knots |
|
Pump |
: 4 units EBARA 2”+Dynamo 5,5 HP 4 kW |
|
OWS |
: 1 unit OWS 0,25 |
|
Winch Anchor |
: Electric Motor |
|
Chain Anchor |
: Size 5/8, 3 Left Length, 3 Right Length |
|
Anchor |
: 2 units @300 Kg |
|
Ramp Door |
: Motor |
|
Hydraulic |
: Hydraulic - Manual |
|
Deck |
: Covered by wood 5 cm |
|
Tether Rope |
: 1 x 50 meter, 1 x 50 meter |
|
Safety |
|
|
Life Graft |
: 2 pcs @ 10 persons |
|
Life Jacket |
: 12 pcs Model WCYC93-1 |
|
Landing Boy |
: 4 pcs Model XT 5555 (720X440) |
|
Smoke Signal |
: 1 pc |
|
Parachute Signal |
: 3 pcs |
|
Red Hand Flare |
: 3 pcs |
|
Flag Signal |
: 1 set |
|
Nozzle Extinguishes |
: 1 pc 2” |
|
Fire Hose |
: 1 pc Size 2” x 30 meter |
|
Siren |
: 1 pc |
|
Bell |
: 1 pc |
|
Fire Extinguisher |
: 4 pcs ABC Powder @ 6 kg |
|
Navigation Equipment |
|
|
Binocular |
: 1 pc |
|
Satellite |
: 1 unit FURUNO GP 32 |
|
Magnetic Compass |
: 1 unitDAIKO T 150, 6” |
|
Radar |
: 1 unitFURUNO 1715 Mk-II |
|
Communication |
|
|
Radio SSB |
: 1 unit ICOM 718 |
|
Radio VHF |
: 1 unit ICOM 302 |
|
Other |
|
|
Television |
: 1 unit 20” |
|
Sleeping Equipment |
: 11 persons ABK (bedsheet+bed+pillow) |
|
Kitchen Equipment |
: 1 unit Refrigerator 1 (one) door |
| : 1 unit Small freezer | |
| : 1 unit Gas Stove HITACHI + 2 Tubes gas LPG @ 6 kg | |
|
|
|
|
Plate of Ship |
|
| Keel | : 12 mm |
| Hull | : 10 mm |
| Bottom | : 10 mm |
| Deck | : 8 mm |
| Partition | : 8 mm |
| Frame | : 8 mm |
